SF1200
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
- Category
- Ultrafast Rectifier
- Datasheet
- SF1200
Product Spectation
| Parameter | Symbol | Value |
|---|---|---|
| Maximum Recurrent Peak Reverse Voltage | VRRM | 1200V |
| Maximum RMS Voltage | VRMS | 840V |
| Maximum DC blocking Voltage | VDC | 1200V |
| Reverse avalanche breakdown voltage at IR = 0.1 mA | V(BR)R | 1250V |
| Maximum Average Forward Rectified Current 3/8”lead length at Ta =55°C | If(av) | 1A |
| Peak Forward Surge Current 8.3ms single half sine-wave superimposed on rated load | IFSM | 30A |
| Maximum Forward Voltage at rated Forward Current and 25°C | Vf | 3.4V |
| Non Repetitive Reverse Avalanche Energy | ER | 10 |
| Maximum DC reverse current at Ta = 25°C rated DC blocking voltage per leg Ta = 125°C [Ta=25°C] | Ir | 5μA |
| Maximum DC reverse current at Ta = 25°C rated DC blocking voltage per leg Ta = 125°C [Ta=125°C] | Ir | 50μA |
| Maximum Reverse Recovery Time | TRR | 75ns |
| Typical Thermal Resistance | Rth(ja) | 45°C/W |
| Maximum thermal resistance per leg | Rth(jc) | 25°C/W |
| Typical Junction Capacitance | Cj | 10.5pF |
| Storage and Operating Junction Temperature | TSTG, Tj | -55to+175 |
| Maximum DC Reverse Current Ta =25℃ at rated DC blocking voltage Ta =125℃ | Ir | - |
| Maximum DC Reverse Current Ta =25℃ at rated DC blocking voltage Ta =125℃ | Ir | - |
Features
- Very low switching losses
- Glass passivated
- Low reverse current
- High reverse voltage
- Hermetically sealed package
Mechanical Data
- Terminal
- Plated axial leads solderable per J-STD-002
- Polarity
- color band denotes cathode end
- Mounting Position
- any
Notes
- [1]Reverse Recovery Condition If =0.5A, Ir =1.0A, Irr =0.25A
- [2]Lead length I =10mm, TL= constant
- [3]Measured at 1.0 MHz and applied Vr=4.0V
